100W SOLAR PANEL
Product Details:
Product Description
Owing to the dedicated effort of our personnel, we have been able to satisfy the diversified necessities of our valuable clients by supplying the high quality range of 100W SOLAR PANEL. The panel has optimum performance & robust construction. This solar panel is manufactured by using high quality components with the edge of innovative technology under the supervision of experts. The product is highly demanded for its durable use and easy installation. The 100W SOLAR PANEL is highly cost effective and eco-friendly in nature.
Main Features:
- Longer service life
- Minimum maintenance
- High performance
TECHNICAL SPECIFICATION
Electrical Parameters for 100W solar panel
| Model | ASP36C100 |
| Rated Power(Pmax) watt | 100 |
| Volt at Max. power(Vmp in volt) | 17 |
| Open circuit voltage(Voc in volt) | 21.35 |
| Current at Max. Power(Imp in Amp) | 5.88 |
| Short circuit current(Isc in Amp) | 6.3 |
| Fill factor(FF) | >70 |
| Module efficiency(%) | 14 |
| Standard Test Condition | Irradiance :1000W/M2 temp: 25.C, & AM:1.5G spectrum |
| Temp.Coeff. of Pmax(%/K) | -0.44 |
| Temp.Coeff. of Voltage(mV/K) | -2.13 |
| Temp.Coeff. of Current(mA/K) | 4.46 |
| Max. system voltage(Volt) | 600 |
| Noct(Nominal Operating Cell temp in .c | 47.0+-2 |
| Tolarence of rated power(%) | +-3 |
Mechanical Parameters
| Family | No.of Cells | Cells | Glass | Alu.Frame | Junction Box | Cable & Connector | Dimension | Weight |
| ASP36C | 9x4 | Poly | High transmission, low iron.tempered and textured glass.3.2mm | Silver Anodized Aluminum Alloy | 3 Rail,2 Diodes | N/A | 1075 X 661 X 35(mm) or 42.32 x 26.02 x 1.37 (inch) | 8.05 K.G |
*WARRANTY: SOLAR PANEL PERFORMANCE WARRANTY 25 YEARS.
